IMPORTANT NOTICE:

Among the 1 set of products, you can choose different color combinations, such as: 6 sensor products, you can choose Black 2, White 2, Red 2 ... If you need to change, leave us a message when you submit the order.

Product features:

1>This product adopts double digital display, obstacle distance before and after the automobile

independent display

2>The product with four voices (voice / buzzer / mute / voice + buzzer), cross cutting exchange

3>Display with 7 adjustable volume

4>Can independently display the direction of 6 obstacles

5>Full-weather design, anti-wind, anti-sand, anti-fog, anti-frost, anti-ice, anti-snow, anti-rain

sensor systems for enhanced coverage and detection.

6>Sound alarm: Heart beat type, more recent alarm more rapidly

Product parameters

1>Digital LCD display (number & light). Help to provide increased safety for passengers,

pedestrians and family members who happen to be around the moving vehicle

2>Specifications:

3>Rate voltage: 12V DC

4>Rate operating range: 10.5V - 16V DC

5>Rate current: 100mA - 300mA

6>Ultrasonic frequency: 40KHz

7>Control moudle working temperature: -30 - 80 celcius degree

8>Display working temperature: -20 - 70 celcius degree

9>Sensor diameter: 22mm

10>Installation mode: Drilling

1：The distance between the front and the left obstacle

2：The distance between the two sensors in the middle of the vehicle to detect the obstacle

3：The distance to the right front of the obstacle

4：The distance between the nearest obstacle


A is the volume decrease,
B is the sound switch button,
C is the volume increase
